Laboratory Instrument Energy Meter Manufacturer,Supplier and Exporter in India
Product Code : EL-OLE-11240
Quick Answer: The Laboratory Instrument Energy Meter plugs into a wall electric outlet and measures power, voltage and current, with a maximum operating current of 16 A at 230 V AC. Readings appear on an LCD display.
Last updated: October 2026
Key Features
Measures power, voltage and current
Plugs into a wall electric outlet
LCD display
Real wattage display 0–3680 W; current display 0.000–16.000 A
Total energy display 0.000–9999 kWh; timing display up to 9999 days
Technical Specifications
Specification
Value
Operating voltage
230 V AC
Operating current
Max 16 A
Meter's own power consumption
0.5 W
Real wattage display
0–3680 W
Current display
0.000–16.000 A
Total energy display
0.000–9999 kWh
Timing display
0 second–9999 days
Overall size
200 x 145 x 110 mm
Weight
1.2 kg
Package
2-pin plug, 1 x power meter
About This Product
This energy meter measures electrical energy consumption. It plugs into a wall outlet, uses 0.5 W itself, and shows power, voltage, current and total kWh on its LCD.
Frequently Asked Questions
Q1. What is the maximum operating current? 16 A at 230 V AC. The real wattage display covers 0–3680 W.
Q2. What is in the package? A 2-pin plug and 1 x power meter.
