Screen Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-SM-11060
Quick Answer: The Screen Microscope combines an LCD display and an inner CCD with an articulated free trinocular head, inclined at 30°, and plan achromatic 4X, 10X, 40X and 100X objectives. Illumination is a 3W LED lamp with a Kohler illumination system.
Last updated: October 2026
Key Features
- Articulated free trinocular head, 30° inclined, interpupillary distance 50-75mm
- PL10X/23mm high eyepiece with ±5 diopter adjustment; tube Φ30mm
- Backward quadruple objective nosepiece, with quintuple as an option
- Working stage 220X148mm with a 76X50mm double mechanical stage, precision 0.1mm, damped double slide clamp
- Abbe condenser N.A. 1.25; coaxial coarse and fine focusing, 0.002mm
- LCD display 800X600 with highest mode 1024X768@75Hz
Technical Specifications
| Specification | Value |
|---|---|
| Head | Articulated free trinocular, 30° inclined |
| Interpupillary distance | 50-75mm |
| Eyepiece | PL10X/23mm high eyepiece |
| Diopter adjustment | ±5 |
| Tube | Φ30mm |
| Objectives | Plan achromatic 4X, 10X, 40X, 100X |
| Nosepiece | Backward quadruple (optional quintuple) |
| Working stage | 220X148mm |
| Mechanical stage | X-axis low hand position double mechanical stage, 76X50mm, precision 0.1mm, damped double slide clamp |
| Condenser | Abbe, N.A. 1.25 |
| Focusing | Coaxial coarse and fine, 0.002mm |
| Lamp | 3W LED with Kohler illumination system |
| Display dimension | 800X600 |
| Colours | 16,777,216 colors |
| Highest mode | 1024X768@75Hz |
| Colour system | PAL/NTSC 4.43/NTSC3.58/SECAM |
| CCD | Inner, 1/3" |
| Horizontal resolution | 700 TV line |
| Pixels | 976(H)X582(V) |
| Gross weight | 10kg |
About This Product
This screen microscope pairs a trinocular head and plan achromatic objectives with an LCD display and an inner CCD. The CCD has a horizontal resolution of 700 TV line with 976(H)X582(V) pixels, and the display supports PAL/NTSC 4.43/NTSC3.58/SECAM colour systems. The gross weight is 10kg.
Frequently Asked Questions
Q1. Which objectives does it have?
Plan achromatic 4X, 10X, 40X and 100X objectives on a backward quadruple nosepiece; a quintuple nosepiece is optional.
Q2. What size is the stage?
The working stage is 220X148mm, and the X-axis low hand position double mechanical stage is 76X50mm with a precision of 0.1mm.
Q3. What illumination does it use?
A 3W LED lamp with a Kohler illumination system.
Related: Student Microscope range, LCD Display Microscope, Zoom Stereo Microscope.
For a quotation on the Screen Microscope, contact Scientific Equipments.
