1250X Microscope Manufacturer,Supplier and Exporter in India
Product Code : EL-BM-11071
Quick Answer: The 1250X Microscope is a metallurgical microscope with an articulated free binocular or monocular head inclined at 45°, achromatic objectives of 10X and 100X (oil), a 40X metallurgical plan achromatic objective, and a 6V20W halogen lamp with Kohler illumination.
Last updated: October 2026
Key Features
- Articulated free binocular or monocular head, 45° inclined, interpupillary distance 55-75mm
- WF10X eyepiece and WF10X eyepiece with 0.1mm micrometer (0.01mm/scale); optional WF12.5X
- Achromatic objectives 10X and 100X (s, oil); metallurgical plan achromatic objective 40X (s)
- Double-layer mechanical stage 200X180mm with plates of Φ10 and Φ20mm; moving range 70X50mm
- Rack and pinion coaxial coarse and fine focusing with tension adjustment and stage height limit knob
- Built-in 6V20W halogen lamp, brightness adjustable, with Kohler illumination and blue, green, yellow and glass filters
Technical Specifications
| Specification | Value |
|---|---|
| Head | Articulated free binocular/monocular, 45° inclined, interpupillary distance 55-75mm |
| Eyepieces | WF10X; WF10X with 0.1mm micrometer, 0.01mm/scale (optional WF12.5X) |
| Objectives | Achromatic 10X, 100X (s, oil); metallurgical plan achromatic 40X (s) |
| Stage | Double-layer mechanical, 200X180mm, plates Φ10 and Φ20mm |
| Moving range | 70X50mm |
| Focusing | Coaxial coarse and fine, rack and pinion, tension adjustment, stage height limit knob |
| Illumination | Built-in halogen lamp 6V20W, adjustable brightness, Kohler illumination |
| Filters | Blue, green, yellow, glass |
| Gross weight | 10kg |
About This Product
This metallurgical microscope has an articulated head that adjusts for interpupillary distances of 55-75mm, and a WF10X eyepiece with a 0.1mm micrometer scaled at 0.01mm is listed alongside the standard WF10X. The 200X180mm stage comes with plates of Φ10 and Φ20mm, and focusing uses a rack and pinion with tension adjustment and a stage height limit knob.
Frequently Asked Questions
Q1. Is a measuring eyepiece included?
Yes. A WF10X eyepiece with a 0.1mm micrometer at 0.01mm/scale is listed alongside a standard WF10X eyepiece. A WF12.5X eyepiece is optional.
Q2. Which filters are supplied?
Blue, green, yellow and glass filters are listed with the Kohler illumination system.
Related: Biological Microscope range, Mini Portable Metallurgical Microscope, 1000X Microscope.
For a quotation on the 1250X Microscope, contact Scientific Equipments.
